Spacer LPR820M

PCB spacer LPR820M

Spacer with snap-on mounting on both sides for distance length 4.8 to 15.9 mm. Easily releasable by pressing the nose.

Description
Close
Product description: PCB spacer LPR820M

Product variants

5 variant(s) found
Didn't find your desired product variant in the list? However, it is in the drawing! Click here: Product enquiry
402372
LPR 8201-MINI
402373
LPR 8202-MINI
402374
LPR 8203-MINI
402375
LPR 8204-MINI
402376
LPR 8205 MINI
Distance height in mm 4,8 6,4 9,5 12,7 15,9
Mounting (A "top") Snap lock Snap lock Snap lock Snap lock Snap lock
Mounting (B "bottom") Snap lock Snap lock Snap lock Snap lock Snap lock
Outer Diameter body in mm 4,4 4,4 4,4 4,4 4,4
Material nylon 66 nylon 66 nylon 66 nylon 66 nylon 66
Fire protection class UL 94 V-0 UL 94 V-0 UL 94 V-0 UL 94 V-0 UL 94 V-0
Temperature range -40°C - +85°C -40°C - +85°C -40°C - +85°C -40°C - +85°C -40°C - +85°C
Colour natural natural natural natural natural
Ø Mounting hole (B "bottom") in mm 3,18 3,18 3,18 3,18 3,18
Overlap (B "bottom") in mm 4 4 4 4 4
Ø Mounting hole (A "top") in mm 3,18 3,18 3,18 3,18 3,18
Overlap (A "top") in mm 4 4 4 4 4
Panel thickness (A "top") in mm 0,79 - 1,98 0,79 - 1,98 0,79 - 1,98 0,79 - 1,98 0,79 - 1,98
Panel thickness (B "bottom") in mm 0,79 - 1,98 0,79 - 1,98 0,79 - 1,98 0,79 - 1,98 0,79 - 1,98
