Drawing rivet plastic PNKT
Rivet plastic PNKT

Plastic rivet PNKT

Rivet with knob diameter 10 or 12 mm and 8 mm height. For hole sizes 3.1 up to 4.2 mm and panel thickness from 1 to 8.5 mm. Releasable rivet.

Description
Close
Product description: Plastic rivet PNKT

Product variants

11 variant(s) found
Didn't find your desired product variant in the list? However, it is in the drawing! Click here: Product enquiry
402786
PNK T 3035 SCHWARZ
402787
PNK T 3045 SCHWARZ
402788
PNK T 3055 SCHWARZ
402789
PNK T 3065 SCHWARZ
402790
PNK T 3080 SCHWARZ
402791
PNK T 3545 SCHWARZ
402792
PNK T 3555 SCHWARZ
402793
PNK T 3570 SCHWARZ
402794
PNK T 4070 SCHWARZ
402795
PNK T 4080 SCHWARZ
402796
PNK T 4100 SCHWARZ
Material nylon 6 nylon 6 nylon 6 nylon 6 nylon 6 nylon 6 nylon 6 nylon 6 nylon 6 nylon 6 nylon 6
Fire protection class UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2
Temperature range -40°C - +115°C -40°C - +115°C -40°C - +115°C -40°C - +115°C -40°C - +115°C -40°C - +115°C -40°C - +115°C -40°C - +115°C -40°C - +115°C -40°C - +115°C -40°C - +115°C
Colour black black black black black black black black black black black
Ø Rivet head in mm 10 10 10 10 10 10 10 10 12 12 12
Height rivet head in mm 8 8 8 8 8 8 8 8 8 8 8
Height hull in mm 3,5 4,5 5,5 6,5 8 4,5 5,5 7 7 8 10
Rivet diameter in mm 3 3 3 3 3 3,5 3,5 3,5 4 4 4
Rivet length in mm 6,6 6,6 6,6 9 9 6,6 6,6 9 11,2 11,2 11,2
Ø Mounting hole in mm 3,1 - 3,2 3,1 - 3,2 3,1 - 3,2 3,1 - 3,2 3,1 - 3,2 3,6 - 3,7 3,6 - 3,7 3,6 - 3,7 4,1 - 4,2 4,1 - 4,2 4,1 - 4,2
Model Rivet (with piston) Rivet (with piston) Rivet (with piston) Rivet (with piston) Rivet (with piston) Rivet (with piston) Rivet (with piston) Rivet (with piston) Rivet (with piston) Rivet (with piston) Rivet (with piston)
