Oil filled linear potentiometer WGO40
Linear position sensor with wirewound element, hermetically sealed, measuring ranges 100–300 mm for harsh environments
- Independent linearity up to 0.1%
- Service life over 10 million movements
- Actuation speed < 2 m/s
- Operating temperature −30…+60 °C
- Protection IP55
- Power rating up to 3 W
Specifications
| Effective electrical travel | From 100 to 300 mm in 3 variants |
|---|---|
| Sensor Technology | Potentiometric |
| Protection Class | IP55 |
| Resolution | Analogue stepped, dep. on resistance value |
| Mechanical Detection Type | Front side rod without spring return |
| Electrical Outlet Type | Solder contacts, Round Cable, Connector |
| Mounting | Ball Joints |
| Electr. output signal | (voltage - potentiometric) |
| Ind. linearity (best) | ±0.1% … ±0.5% (dep. o. travel & option) |
| Actuating speed | < 2 m/s |
| Max. operating temperature | +60 °C |
| Min. operating temperature | -30 °C |
| Minimum overall length | Medium (15 to 50 cm), Long (> 50 cm) |
| Supply voltage | Potentiometric |
