Drawing standoff LPR890
Standoff LPR890

Plastic PCB standoff LPR890

Hexagonal standoff with M3 or M4 male and female thread for distance length 10 to 30 mm

Description
Close
Product description: Plastic PCB standoff LPR890

Product variants

10 variant(s) found
Didn't find your desired product variant in the list? However, it is in the drawing! Click here: Product enquiry
402489
LPR 8901-M4
402490
LPR 8902-M4
402491
LPR 8903-M4
402492
LPR 8904-M4
402493
LPR 8905-M4
403056
LPR 8901-M3
403057
LPR 8902-M3
403058
LPR 8903-M3
403059
LPR 8904-M3
403060
LPR 8905-M3
Distance height in mm 10,0 15,0 20,0 25,0 30,0 10,0 15,0 20,0 25,0 30,0
Model Type B (male/ female) Type B (male/ female) Type B (male/ female) Type B (male/ female) Type B (male/ female) Type B (male/ female) Type B (male/ female) Type B (male/ female) Type B (male/ female) Type B (male/ female)
Ø Female thread in mm M4 M4 M4 M4 M4 M3 M3 M3 M3 M3
Thread depth (inside) in mm 6,5 6,5 6,5 6,5 6,5 5,5 5,5 5,5 5,5 5,5
Ø Male thread in mm M4 M4 M4 M4 M4 M3 M3 M3 M3 M3
Thread length (outside) in mm 6,0 6,0 6,0 6,0 6,0 5,0 5,0 5,0 5,0 5,0
Outer Diameter body in mm 7 7 7 7 7 5,5 5,5 5,5 5,5 5,5
Material nylon 66 nylon 66 nylon 66 nylon 66 nylon 66 nylon 66 nylon 66 nylon 66 nylon 66 nylon 66
Material of thread PA66-RV PA66-RV PA66-RV PA66-RV PA66-RV PA66-RV PA66-RV PA66-RV PA66-RV PA66-RV
Fire protection class UL 94 HB UL 94 HB UL 94 HB UL 94 HB UL 94 HB UL 94 HB UL 94 HB UL 94 HB UL 94 HB UL 94 HB
Temperature range -30°C - +110°C -30°C - +110°C -30°C - +110°C -30°C - +110°C -30°C - +110°C -30°C - +110°C -30°C - +110°C -30°C - +110°C -30°C - +110°C -30°C - +110°C
Colour natural natural natural natural natural natural natural natural natural natural
