Drawing spacer LPR830
Spacer LPR830

PCB spacer LPR830

Spacer with adhesive film on one side and snap-on mounting on the other. Releasable by pushing the nose in. For distance length 4.8 to 15.9 mm

Description
Close
Product description: PCB spacer LPR830

Product variants

5 variant(s) found
Didn't find your desired product variant in the list? However, it is in the drawing! Click here: Product enquiry
402383
LPR 8301-MINI
402384
LPR 8302-MINI
402385
LPR 8303-MINI
402386
LPR 8304-MINI
404453
LPR 8305-MINI
Distance height in mm 4,8 6,4 9,5 12,7 15,9
Mounting (A "top") Snap lock Snap lock Snap lock Snap lock Snap lock
Mounting (B "bottom") Adhesive film Adhesive film Adhesive film Adhesive film Adhesive film
Outer Diameter body in mm 4,4 4,4 4,4 4,4 4,4
Material nylon 66 nylon 66 nylon 66 nylon 66 nylon 66
Fire protection class UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2 UL 94 V-2
Colour natural natural natural natural natural
Ø Mounting hole (A "top") in mm 3,18 3,18 3,18 3,18 3,18
Overlap (A "top") in mm 8,7 8,7 8,7 8,7 8,7
Panel thickness (A "top") in mm 1,57 1,57 1,57 1,57 1,57
