Plastic rivet LPR13
Rivet for hole sizes 3.2 up to 7.8 mm. Cover holes in the panel from Ø8 to Ø14 mm. Also used to fix two or more PCBs.
| 404560 LPR 1309 | 404564 LPR 1313 | 404565 LPR 1314 | 404566 LPR 1315 | 406451 LPR 1309-B | |
|---|---|---|---|---|---|
| Material | acetal | acetal | acetal | acetal | acetal |
| Fire protection class | UL 94 HB | UL 94 HB | UL 94 HB | UL 94 HB | UL 94 HB |
| Temperature range | -50°C - +100°C | -50°C - +100°C | -50°C - +100°C | -50°C - +100°C | -50°C - +100°C |
| Colour | natural | natural | natural | natural | black |
| Ø Rivet head in mm | 8,0 | 12,0 | 14,0 | 12,0 | 8,0 |
| Height rivet head in mm | 1,5 | 2,0 | 2,2 | 2,0 | 1,5 |
| Rivet diameter in mm | 2,7 | 3,9 | 4,2 | 3,8 | 2,7 |
| Rivet length in mm | 13,0 | 17,0 | 19,0 | 17,5 | 13,0 |
| Ø Mounting hole in mm | 3,2 | 6,4 | 7,8 | 5,5 | 3,2 |
| Panel thickness in mm | 1,0 - 4,5 | 1,5 - 6,5 | 1,5 - 7,0 | 1,5 - 6,5 | 1,0 - 4,5 |
| Model | Mini-expanding rivet | Mini-expanding rivet | Mini-expanding rivet | Mini-expanding rivet | Mini-expanding rivet |
